Electric Pumps
EL Series High Head
49-188 hp / 264-440 gpm
EL Series High Head
High-performance electric dredging pumps
The EL Series High Head models are high-performance electric pumps designed for exceptional abrasion resistance and capable of handling material concentrations of up to 70%. Engineered for industrial, mining, and dredging operations across various sectors, they ensure optimal efficiency and sustained productivity.
High-efficiency agitator – Reversible and constructed from high-chrome materials for extended service life and reliable lifting of settled sediments.
Low rotational speed – Minimizes wear and preserves long-term performance.
Robust construction – Built with heavy-duty, abrasion-resistant components to handle demanding, high-solid content mixtures.
EL604, EL604 S and EL1204 are also available in super duplex stainless steel (CD3MN).
Model Specifications
| Model | Delivery (in) | Capacity (gpm) | Head (ft) | Power (HP) | RPM (60 Hz) | Solid Handling (in) | Weight (lb) |
|---|---|---|---|---|---|---|---|
| EL354 | 4 | 264 | 151 | 49 | 1758 | 1.4 | 1580 |
| EL354 S | 4 | 264 | 151 | 59 | 1782 | 1.4 | 1580 |
| EL604 | 6 | 881 | 138 | 100 | 1776 | 2.4 | 2425 |
| EL604 S | 6 | 881 | 138 | 120 | 1776 | 2.4 | 2460 |
| EL604 HH | 4 | 440 | 161 | 100 | 1776 | 1.4 | 2755 |
| EL604 SHH | 4 | 440 | 164 | 120 | 1776 | 1.4 | 2755 |
| EL1204 | 6 | 881 | 154 | 120 | 1776 | 2.4 | 2755 |
| EL1204 HH | 4 | 440 | 236 | 120 | 1776 | 1.4 | 2755 |
| EL1204 UHH | 4 | 440 | 236 | 160 | 1740 | 0.8 | 4080 |
| EL1204 SUHH | 4 | 440 | 236 | 188 | 1740 | 0.8 | 4250 |
